MAX14930EAWE+T

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description DGTL ISO 2750VRMS 4CH GP 16SOIC
PDF
/
Inventory: 6946
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Pulse Width Distortion (PWD) 2.6 ns
Isolated Power No
Inputs - Side 1/Side 2 4/0
Common Mode Transient Immunity (Min) 25kV/μs (Typ)
Propagation Delay tpLH / tpHL (Max) 27.5ns, 28.8ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2ns 2ns
Data Rate 25Mbps
Propagation Delay 28.8 ns
Number of Channels 4
Voltage - Isolation 2750Vrms
Base Part Number MAX14930
Voltage - Supply 1.71V~5.5V
Technology Capacitive Coupling
Type General Purpose
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 13 Weeks
