MAX14930BASE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
Digital Isolator 16-Pin SOIC N Tube
PDF
/
Buying Options
Total Price: USD $4.99
Unit Price: USD $4.9896
≥1 USD $4.9896
≥10 USD $4.48448
≥100 USD $4.239488
≥500 USD $3.674264
≥1000 USD $3.485856
≥3000 USD $3.127872
Inventory: 460
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2015
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type General Purpose
Technology Capacitive Coupling
Voltage - Supply 1.71V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Base Part Number MAX14930
Voltage - Isolation 2750Vrms
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.71V
Number of Channels 4
Propagation Delay 28.8 ns
Data Rate 25Mbps
Rise / Fall Time (Typ) 2ns 2ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 27.5ns, 28.8ns
Common Mode Transient Immunity (Min) 25kV/μs (Typ)
Inputs - Side 1/Side 2 4/0
Isolated Power No
Pulse Width Distortion (PWD) 2.6 ns
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
