MAX14851AEE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 600VRMS 6CH GP 16QSOP
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Pulse Width Distortion (Max) 2.9ns
Isolated Power No
Inputs - Side 1/Side 2 4/4
Common Mode Transient Immunity (Min) 3.2kV/μs
Propagation Delay tpLH / tpHL (Max) 11.6ns, 11.8ns
Channel Type Bidirectional, Unidirectional
Rise / Fall Time (Typ) 5ns 5ns Max
Data Rate 2Mbps, 50Mbps
Number of Channels 6
Voltage - Isolation 600Vrms
Base Part Number MAX14851
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Voltage - Supply 3V~5.5V
Technology Capacitive Coupling
HTS Code 8542.39.00.01
Type General Purpose
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
