MAX14483AAP+
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Isolators / Digital Isolators
Description
DGT ISOL 3750VRMS 6CH SPI 20SSOP
PDF
/
Buying Options
Total Price: USD $7.26
Unit Price: USD $7.26
≥1 USD $7.26
≥10 USD $6.55424
≥100 USD $6.249602
≥500 USD $5.426467
≥1000 USD $5.182602
≥3000 USD $4.725301
Inventory: 1110
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Technical
Operating Temperature -40°C~125°C
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type SPI
HTS Code 8542.39.00.01
Technology Capacitive Coupling
Voltage - Supply 1.71V~5.5V
Base Part Number MAX14483
Voltage - Isolation 3750Vrms
Number of Channels 6
Data Rate 25Mbps
Rise / Fall Time (Typ) 1.6ns 1.4ns Max
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 32.5ns, 33.6ns
Common Mode Transient Immunity (Min) 50kV/μs (Typ)
Inputs - Side 1/Side 2 2/4
Isolated Power No
Pulse Width Distortion (Max) 4ns
Compliance
RoHS Status ROHS3 Compliant
