LTM2895CY#PBF image
Favorite
LTM2895CY#PBF image
Favorite
RoHS
RoHS RoHS compliant
Package 36-BGA
Category Isolators / Digital Isolators
Description DGTL ISOL 6000VRMS 9CH SPI 36BGA
PDF
/
Buying Options
Total Price: USD $17.88
Unit Price: USD $17.8816
≥1 USD $17.8816
≥10 USD $16.43312
≥100 USD $15.752352
≥500 USD $13.878973
≥1000 USD $13.1978
≥3000 USD $12.34633
Inventory: 128
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)

Physical

Mounting Type Surface Mount
Package / Case 36-BGA
Surface Mount YES
Number of Pins 36

Technical

Operating Temperature 0°C~70°C
Packaging Tray
Published 2016
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 36
Type SPI
Technology Magnetic Coupling
Voltage - Supply 3V~5.5V
Terminal Position BOTTOM
Terminal Form BALL
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1mm
Base Part Number LTM2895
Pin Count 36
Voltage - Isolation 6000Vrms
Number of Channels 9
Supply Current-Max 15mA
Data Rate 100Mbps
Differential Output NO
Output Polarity TRUE
Input Characteristics STANDARD
Rise / Fall Time (Typ) 10ns 10ns
Driver Number of Bits 1
Channel Type Bidirectional, Unidirectional
Receiver Number of Bits 1
Propagation Delay tpLH / tpHL (Max) 150ns, 150ns
Common Mode Transient Immunity (Min) 50kV/μs
Inputs - Side 1/Side 2 8/4
Isolated Power No

Dimensions

Height Seated (Max) 2.26mm
Length 15mm
Width 6.25mm

Compliance

RoHS Status ROHS3 Compliant
