LTM2810IY-I#PBF
RoHS
RoHS compliant
RoHS compliantPackage 36-BGA Module
Category Isolators / Digital Isolators
Description
DGTL ISOL 7500VRMS 6CH I2C 36BGA
PDF
/
Buying Options
Total Price: USD $116.13
Unit Price: USD $116.12515
≥1 USD $116.12515
≥10 USD $112.25485
≥100 USD $100.64205
Inventory: 1151
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Surface Mount
Package / Case 36-BGA Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series μModule?
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Type I2C
Technology Magnetic Coupling
Voltage - Supply 3V~5.5V
Voltage - Isolation 7500Vrms
Number of Channels 6
Data Rate 400kHz
Rise / Fall Time (Typ) 350ns 250ns Max
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 500ns, 500ns
Common Mode Transient Immunity (Min) 50kV/μs
Inputs - Side 1/Side 2 3/3
Isolated Power Yes
Pulse Width Distortion (Max) 50ns
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
