HCPL-901J-000E

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description Digital Isolator CMOS 4-CH 110MBd 16-Pin SOIC W Tube
PDF
/
Buying Options
Total Price: USD $17.59
Unit Price: USD $17.5912
≥1 USD $17.5912
≥10 USD $16.16472
≥100 USD $15.494336
≥500 USD $13.651792
≥1000 USD $12.98176
≥3000 USD $12.144211
Inventory: 430
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 17 Weeks

Physical

Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16

Technical

Operating Temperature -55°C~125°C
Packaging Tube
Published 2013
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type General Purpose
Technology GMR (Giant Magnetoresistive)
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Voltage - Isolation 2500Vrms
Operating Supply Voltage 5.5V
Supply Voltage-Min (Vsup) 3V
Number of Channels 4
Nominal Supply Current 4mA
Power Dissipation 150mW
Propagation Delay 15 ns
Turn On Delay Time 18 ns
Data Rate 110MBd
Rise / Fall Time (Typ) 1ns 1ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 15ns, 15ns
Common Mode Transient Immunity (Min) 15kV/μs
Inputs - Side 1/Side 2 2/2
Isolated Power No
Pulse Width Distortion (PWD) 3 ns

Dimensions

Length 10.287mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
