ADUM6211BRSZ-RL7
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 3750VRMS 2CH GP 20SSOP
PDF
/
Buying Options
Total Price: USD $3.75
Unit Price: USD $3.750955
≥1 USD $3.750955
≥10 USD $3.267808
≥30 USD $2.980283
≥100 USD $2.688819
≥500 USD $2.554903
≥1000 USD $2.49451
Inventory: 3506
Minimum: 1
-
+
Technical Details
Technical
Voltage - Isolation 3750Vrms
Output Voltage 3.3V
Input Voltage-Nom 3.3V
Power Supplies 3.3/5V
Number of Channels 2
Propagation Delay 35 ns
Turn On Delay Time 15 ns
Input Voltage (Min) 3V
Data Rate 25Mbps
Input Voltage (Max) 3.6V
Control Technique PULSE WIDTH MODULATION
Qualification Status Not Qualified
Pin Count 20
Base Part Number ADUM6211
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology Magnetic Coupling
Subcategory Other Analog ICs
HTS Code 8543.70.99.60
Additional Feature ALSO WORKS WITH 5 VOLT INPUT VOLTAGE WHICH GIVES 5VOLT AND 3.3 VOLT OUTPUT
Type General Purpose
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series IsoPower?, iCoupler?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Pulse Width Distortion (PWD) 3 ns
Isolated Power Yes
Inputs - Side 1/Side 2 1/1
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 35ns, 35ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns 2.5ns
Physical
Number of Pins 20
Surface Mount YES
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 22 Weeks
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
