ADUM4402WARWZ
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 5KV 4CH GEN PURP 16SOIC
PDF
/
Buying Options
Total Price: USD $26.85
Unit Price: USD $26.84795
≥1 USD $26.84795
≥10 USD $22.02955
≥100 USD $21.3408
≥500 USD $20.653
≥1000 USD $19.96425
Inventory: 19
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Physical
Contact Plating Tin
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Series Automotive
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type General Purpose
Technology Magnetic Coupling
Voltage - Supply 3.135V~5.5V
Base Part Number ADUM4402
Pin Count 16
Voltage - Isolation 5000Vrms
Number of Channels 4
Propagation Delay 100 ns
Data Rate 1Mbps
Rise / Fall Time (Typ) 2.5ns 2.5ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Common Mode Transient Immunity (Min) 25kV/μs
Inputs - Side 1/Side 2 2/2
Isolated Power No
Pulse Width Distortion (PWD) 40 ns
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
