ADUM2201ARWZ-RL
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGTL ISO 5KV 2CH GEN PURP 16SOIC
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 75937
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Length 10.3mm
Technical
Pulse Width Distortion (PWD) 40 ns
Isolated Power No
Inputs - Side 1/Side 2 1/1
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 150ns, 150ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 10ns 10ns
Data Rate 1Mbps
Propagation Delay 150 ns
Nominal Supply Current 800μA
Number of Channels 2
Voltage - Isolation 5000Vrms
Pin Count 16
Base Part Number ADUM2201
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology Magnetic Coupling
Terminal Finish Matte Tin (Sn)
Type General Purpose
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series iCoupler?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 16 Weeks
Alternative Model
