ADUM141E0BRWZ
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
16-SOIC (0.295 7.50mm Width) 4 3/1 General Purpose Digital Isolator 75kV/mus 3750Vrms 150Mbps -40C~125C
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
≥3000 USD $1.7898
Inventory: 22549
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Series iCoupler?
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Type General Purpose
Terminal Finish Matte Tin (Sn)
Additional Feature IT ALSO OPERATES AT 2.5, 3.3, 5 V
Technology Magnetic Coupling
Voltage - Supply 1.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 1.27mm
Base Part Number ADUM141
Pin Count 16
Voltage - Isolation 3750Vrms
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.7V
Number of Channels 4
Propagation Delay 13 ns
Data Rate 150Mbps
Rise / Fall Time (Typ) 2.5ns 2.5ns
Channel Type Unidirectional
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Common Mode Transient Immunity (Min) 75kV/μs
Inputs - Side 1/Side 2 3/1
Isolated Power No
Pulse Width Distortion (PWD) 3 ns
Dimensions
Height Seated (Max) 2.65mm
Length 10.3mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
