ADUM140D0BRQZ-RL7
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
16-SSOP (0.154 3.90mm Width) 4 4/0 General Purpose Digital Isolator 75kV/mus 3000Vrms 150Mbps -40C~125C
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7127
≥1 USD $6.7127
≥10 USD $5.5081
≥100 USD $5.3352
≥500 USD $5.16325
≥1000 USD $4.9913
≥3000 USD $4.47545
Inventory: 13216
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 1.75mm
Technical
Pulse Width Distortion (Max) 3ns
Isolated Power No
Inputs - Side 1/Side 2 4/0
Common Mode Transient Immunity (Min) 75kV/μs
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns 2.5ns
Data Rate 150Mbps
Number of Channels 4
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 5.5V
Voltage - Isolation 3000Vrms
Pin Count 16
Base Part Number ADUM140
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.7V~5.5V
Technology Magnetic Coupling
Type General Purpose
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code no
Series iCoupler?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 16
Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 8 Weeks
