ADUM130D0BRZ
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
16-SOIC (0.154 3.90mm Width) 3 3/0 General Purpose Digital Isolator 75kV/mus 3000Vrms 150Mbps -40C~125C
PDF
/
Buying Options
Total Price: USD $2.99
Unit Price: USD $2.992
≥1 USD $2.992
≥10 USD $2.68664
≥100 USD $2.539715
≥500 USD $2.2011
≥1000 USD $2.088231
≥3000 USD $1.873766
Inventory: 329
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Series iCoupler?
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Type General Purpose
Technology Magnetic Coupling
Voltage - Supply 1.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 1.8V
Terminal Pitch 1.27mm
Base Part Number ADUM130
Pin Count 16
Pulse Width Distortion (Max) 3ns
Isolated Power No
Inputs - Side 1/Side 2 3/0
Common Mode Transient Immunity (Min) 75kV/μs
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Channel Type Unidirectional
Rise / Fall Time (Typ) 2.5ns 2.5ns
Data Rate 150Mbps
Number of Channels 3
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 5.5V
Voltage - Isolation 3000Vrms
JESD-30 Code R-PDSO-G16
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 9.9mm
Height Seated (Max) 1.75mm
