ADUM1201BRZ
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Digital Isolators
Description
ANALOG DEVICES ADUM1201BRZ Digital Isolator, Dual, 2 Channel, 50 ns, 2.7 V, 5.5 V, SOIC, 8 Pins
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.87237
≥1 USD $0.87237
≥10 USD $0.82299
≥100 USD $0.77641
≥500 USD $0.73246
≥1000 USD $0.691
≥3000 USD $0.65189
Inventory: 227358
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 4mm
Length 5mm
Technical
Pulse Width Distortion (PWD) 3 ns
Isolated Power No
Inputs - Side 1/Side 2 1/1
Common Mode Transient Immunity (Min) 25kV/μs
Propagation Delay tpLH / tpHL (Max) 50ns, 50ns
Number of Input Lines 1
Channel Type Unidirectional
Max Input Current 10μA
Rise / Fall Time (Typ) 2.5ns, 2.5ns
Rise Time 3 ns
Data Rate 10Mbps
Propagation Delay 50 ns
Output Current 35mA
Nominal Supply Current 600μA
Number of Channels 2
Operating Supply Voltage 3V
Voltage - Isolation 2500Vrms
Pin Count 8
Base Part Number ADUM1201
Time@Peak Reflow Temperature-Max (s) 30
Depth 1.5mm
Supply Voltage 3V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.7V~5.5V
Technology Magnetic Coupling
Type General Purpose
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Series iCoupler?
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Factory Lead Time 18 Weeks
