RDC40110D15
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER RDC40110D15 Isolated Board Mount DC/DC Converter, Fixed, Adjustable, 2 Output, 55 V, 176 V, 40 W, 15 V
PDF
/
Buying Options
Total Price: USD $143.63
Unit Price: USD $143.63
≥1 USD $143.63
≥10 USD $135.5
≥100 USD $127.83019
≥500 USD $120.59452
≥1000 USD $113.76841
≥3000 USD $107.32869
Inventory: 7922
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 10.668mm
Technical
Min Input Voltage (DC) 55V
Max Input Voltage (DC) 176V
Current - Output 2 1.35A
Max Output Power 40W
Current - Output 1 1.35A
Voltage - Output 2 -15V
Control Features Enable, Active High
Output Power 40W
Current - Output (Max) 1.35A 1.35A
Voltage - Output 1 15V
Max Output Current 1.35A
Voltage - Isolation 1.5kV
Efficiency 87.5%
Number of Outputs 2
Depth 50.8mm
Max Power Dissipation 40W
Applications ITE (Commercial), Railway
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Size / Dimension 2.00Lx1.60W x 0.42 H 50.8mmx40.6mmx10.7mm
Series RDC (40W)
Published 2014
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
