Q50N-5
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER -5000V 500MW
PDF
/
Buying Options
Total Price: USD $348.88
Unit Price: USD $348.8778
≥1 USD $348.8778
≥10 USD $329.13
≥100 USD $310.5
≥500 USD $292.92453
≥1000 USD $276.34389
Inventory: 4414
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module, 5 Leads
Technical
Operating Temperature -25°C~60°C
Packaging Box
Published 2015
Series XP EMCO - Q (0.5W)
Size / Dimension 0.50Lx0.50W x 0.50 H 12.7mmx12.7mmx12.7mm
Feature Proportional Output
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
Type High Voltage - Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 500mW
Depth 12.7mm
Number of Outputs 1
Qualification Status Not Qualified
Voltage - Isolation 500V
Voltage - Input (Max) 5V
Max Output Current 100μA
Voltage - Output 1 -5000V
Voltage - Input (Min) 0.7V
Current - Output 1 100μA
Max Output Power 500mW
Max Input Voltage (DC) 5V
Min Input Voltage (DC) 700mV
Dimensions
Height 12.7mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
