Q12-5
RoHS
RoHS compliant
RoHS compliantPackage 4-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1200V 500MW
PDF
/
Inventory: 2595
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 12.7mm
Technical
Min Input Voltage (DC) 700mV
Max Input Voltage (DC) 5V
Max Output Power 500mW
Current - Output 1 417μA
Voltage - Input (Min) 0.7V
Voltage - Output 1 1200V
Max Output Current 417μA
Voltage - Input (Max) 5V
Voltage - Isolation 500V
Qualification Status Not Qualified
Number of Outputs 1
Depth 12.7mm
Max Power Dissipation 500mW
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type High Voltage - Isolated Module
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Proportional Output
Size / Dimension 0.50Lx0.50W x 0.50 H 12.7mmx12.7mmx12.7mm
Series XP EMCO - Q (0.5W)
Packaging Box
Operating Temperature -25°C~70°C
Physical
Package / Case 4-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
