P20N
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER -2000V
PDF
/
Inventory: 3437
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 6.096mm
Technical
Min Input Voltage (DC) 5V
Max Input Voltage (DC) 12V
Max Output Power 2mW
Min Output Voltage 0V
Max Output Voltage -2kV
Current - Output (Max) 1μA
Voltage - Output 1 -2000V
Max Output Current 1μA
Output Voltage 0V
Number of Outputs 1
Depth 35.05mm
Applications ITE (Commercial)
Type High Voltage - Non-Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.38Lx0.68W x 0.24 H 35.1mmx17.3mmx6.2mm
Series XP EMCO - P (0.25W)
Packaging Box
Operating Temperature -10°C~70°C
Physical
Package / Case 7-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 14 Weeks
