JWL4048S3V3
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC-DC CONV. 40W, 4:1 INPUT, 1X2
PDF
/
Buying Options
Total Price: USD $94
Unit Price: USD $94
≥1 USD $94
≥10 USD $88.67925
≥100 USD $83.65967
Inventory: 2548
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 25.4mm
Height 10.16mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 75V
Max Output Power 40W
Current - Output 1 8A
Control Features Enable, Active High
Output Power 40W
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Output 1 3.3V
Max Output Current 8A
Output Voltage 3.3V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 89%
Number of Outputs 1
JESD-30 Code R-MDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 50.8mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 26W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Series JWL (40W)
Published 2016
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 17 Weeks
