JTK3048D15

XP Power
RoHS
RoHS RoHS compliant
Package 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC/DC CONVERTER 15V -15V 30W
PDF
/
Buying Options
Total Price: USD $43.99
Unit Price: USD $43.98894
≥1 USD $43.98894
≥10 USD $41.499
≥100 USD $39.15
≥500 USD $36.93396
≥1000 USD $34.84336
Inventory: 3863
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height 10.922mm

Technical

Min Input Voltage (DC) 18V
Max Input Voltage (DC) 75V
Max Output Power 30W
Voltage - Output 2 -15V
Control Features Enable, Active High
Output Power 30W
Current - Output (Max) 1A 1A
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Output 1 15V
Max Output Current 1A
Output Voltage 15V
Voltage - Isolation 1.5kV
Efficiency 90%
Number of Outputs 2
JESD-30 Code S-XDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 25.4mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 30W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OVP, SCP
Size / Dimension 1.00Lx1.00W x 0.43 H 25.4mmx25.4mmx10.9mm
Series JTK30 (30W)
Published 2016
Packaging Tube
Operating Temperature -40°C~100°C

Physical

Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 10 Weeks
