JTK1548S15
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JTK1548S15 Isolated Board Mount DC/DC Converter, 4:1 Input, Fixed, 1 Output, 18 V, 75 V, 15 W, 15 V
PDF
/
Buying Options
Total Price: USD $40.28
Unit Price: USD $40.28
≥1 USD $40.28
≥10 USD $38
≥100 USD $35.84906
Inventory: 6977
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.906mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 75V
Nominal Output Voltage 15V
Max Output Power 15W
Current - Output 1 1A
Control Features Enable, Active High
Output Power 15W
Output Current 1A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Operating Supply Voltage 48V
Max Output Current 1A
Output Voltage 15V
Voltage - Input (Max) 75V
Voltage - Isolation 1.6kV
Efficiency 88%
Number of Outputs 1
JESD-30 Code S-XDMA-T6
Depth 25.4mm
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 15W
Power Rating 15W
Additional Feature SEATED HGT-CALCULATED
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 1.00Lx1.00W x 0.39 H 25.4mmx25.4mmx9.9mm
Series JTK (15W)
Published 2011
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 9 Weeks
