JTH1548D15
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JTH1548D15 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 18 V, 72 V, 15 W, 15 V
PDF
/
Buying Options
Total Price: USD $47.91
Unit Price: USD $47.912
≥1 USD $47.912
≥10 USD $45.2
≥100 USD $42.64151
≥1000 USD $37.95079
Inventory: 9898
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 10.16mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 72V
Current - Output 2 500mA
Max Output Power 15W
Nominal Input Voltage 48V
Current - Output 1 500mA
Voltage - Output 2 -15V
Output Power 15W
Output Current 500mA
Current - Output (Max) 500mA 500mA
Max Output Current 500mA
Output Voltage 15V
Voltage - Isolation 1.5kV
Efficiency 86%
Number of Outputs 2
Depth 50.8mm
Max Power Dissipation 15W
Power Rating 15W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP, UVLO
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Series JTH (15W)
Published 2009
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
