JTF1248D12
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JTF1248D12 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 18 V, 75 V, 12 W, 12 V
PDF
/
Buying Options
Total Price: USD $33.71
Unit Price: USD $33.708
≥1 USD $33.708
≥10 USD $31.8
≥100 USD $30
Inventory: 8753
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 9 Leads
Weight 20g
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Published 2010
Series JTF (12W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature Remote On/Off, OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power Rating 12W
Max Power Dissipation 12W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 31.75mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-P9
Number of Outputs 2
Efficiency 90%
Voltage - Isolation 1.6kV
Output Voltage 12V
Max Output Current 500mA
Operating Supply Voltage 48V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 500mA 500mA
Output Current 500mA
Output Power 12W
Control Features Enable, Active High
Voltage - Output 2 -12V
Current - Output 1 500mA
Max Output Power 12W
Nominal Output Voltage -12V
Current - Output 2 500mA
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 18V
Dimensions
Height 10.16mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
