JTC0424D15

XP Power
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER JTC0424D15Isolated Board Mount DC/DC Converter, 4:1 Input, Through Hole, 4W, 15V, 134mA, -15V, 134mA
PDF
/
Buying Options
Total Price: USD $28.54
Unit Price: USD $28.53944
≥1 USD $28.53944
≥10 USD $26.924
≥100 USD $25.4
≥1000 USD $22.60591
≥3000 USD $21.32633
Inventory: 2554
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height 10.414mm

Technical

Min Input Voltage (DC) 9V
Max Input Voltage (DC) 36V
Current - Output 2 134mA
Max Output Power 4W
Current - Output 1 134mA
Voltage - Output 2 -15V
Output Power 4W
Output Current 134mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Max Output Current 134mA
Output Voltage 15V
Voltage - Isolation 1.5kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 2
Depth 31.75mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 4W
Power Rating 4W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 1.25Lx0.80W x 0.41 H 31.8mmx20.3mmx10.4mm
Series JTC (4W)
Published 2009
Packaging Tube
Operating Temperature -40°C~100°C

Physical

Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 10 Weeks
