JSM2548D15
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER 15V -15V 25W
PDF
/
Buying Options
Total Price: USD $52.5
Unit Price: USD $52.5
≥1 USD $52.5
≥10 USD $49.5283
≥100 USD $46.72481
≥500 USD $44.08001
≥1000 USD $41.58492
≥3000 USD $39.23105
Inventory: 4523
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 10.16mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 75V
Max Output Power 25W
Voltage - Output 2 -15V
Control Features Enable, Active High
Output Power 25W
Current - Output (Max) 840mA 840mA
Voltage - Output 1 15V
Max Output Current 840mA
Voltage - Isolation 1.5kV
Efficiency 89%
Number of Outputs 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 25.4mm
Peak Reflow Temperature (Cel) NOT SPECIFIED
Max Power Dissipation 25W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 1.00Lx1.00W x 0.40 H 25.4mmx25.4mmx10.2mm
Series JSM25 (25W)
Published 2016
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
