JSM1048S3V3
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.3V 10W
PDF
/
Buying Options
Total Price: USD $31.67
Unit Price: USD $31.6728
≥1 USD $31.6728
≥10 USD $29.88
≥100 USD $28.18868
≥500 USD $26.59309
≥1000 USD $25.08782
Inventory: 9542
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 10.16mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 75V
Max Output Power 10W
Current - Output 1 2.5A
Output Power 10W
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Max Output Current 2.5A
Output Voltage 3.3V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 83%
Number of Outputs 1
JESD-30 Code S-MDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 25.4mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 8W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP, UVLO
Size / Dimension 1.00Lx1.00W x 0.40 H 25.4mmx25.4mmx10.2mm
Series JSM10 (10W)
Published 2016
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 6-DIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
