JSM1024S12

XP Power
RoHS
RoHS RoHS compliant
Package 6-DIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 12V 10W
PDF
/
Buying Options
Total Price: USD $29.83
Unit Price: USD $29.83158
≥1 USD $29.83158
≥10 USD $28.143
≥100 USD $26.55
Inventory: 104
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height 10.16mm

Technical

Min Input Voltage (DC) 18V
Max Input Voltage (DC) 36V
Max Output Power 10W
Current - Output 1 830mA
Output Power 10W
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Max Output Current 830mA
Output Voltage 12V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 88%
Number of Outputs 1
JESD-30 Code S-MDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 25.4mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 10W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP, UVLO
Size / Dimension 1.00Lx1.00W x 0.40 H 25.4mmx25.4mmx10.2mm
Series JSM10 (10W)
Published 2016
Packaging Tube
Operating Temperature -40°C~100°C

Physical

Package / Case 6-DIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 15 Weeks
