JSE0848D12
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER 12V -12V 8W
PDF
/
Buying Options
Total Price: USD $31.99
Unit Price: USD $31.9908
≥1 USD $31.9908
≥10 USD $30.18
≥100 USD $28.4717
≥500 USD $26.86009
≥1000 USD $25.33971
Inventory: 2742
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP Module, 6 Leads
Technical
Operating Temperature -40°C~105°C
Packaging Tube
Published 2016
Series JSE08 (8W)
Size / Dimension 0.94Lx0.54W x 0.31 H 23.9mmx13.7mmx8.0mm
Feature SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 8W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 13.7mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-MDMA-P6
Number of Outputs 2
Efficiency 86%
Voltage - Isolation 1.5kV
Output Voltage 12V
Max Output Current 335mA
Voltage - Output 1 12V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 335mA 335mA
Output Power 8W
Voltage - Output 2 -12V
Max Output Power 8W
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 36V
Dimensions
Height 7.874mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Alternative Model
