JHM1012D12
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JHM1012D12 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 9 V, 18 V, 10 W, 12 V
PDF
/
Buying Options
Total Price: USD $56.18
Unit Price: USD $56.18
≥1 USD $56.18
≥10 USD $53
≥100 USD $50
≥500 USD $47.16981
≥1000 USD $44.49982
Inventory: 7141
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 12.7mm
Technical
Min Input Voltage (DC) 9V
Max Input Voltage (DC) 18V
Current - Output 2 420mA
Nominal Output Voltage -12V
Max Output Power 10W
Current - Output 1 420mA
Voltage - Output 2 -12V
Output Power 10W
Output Current 420mA
Current - Output (Max) 420mA 420mA
Max Output Current 420mA
Output Voltage 12V
Voltage - Isolation 4kV
Efficiency 88%
Number of Outputs 2
Depth 31.75mm
Max Power Dissipation 10W
Power Rating 10W
Applications Medical
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OCP, OVP, SCP, UVLO
Size / Dimension 1.25Lx0.80W x 0.50 H 31.8mmx20.3mmx12.7mm
Series JHM (10W)
Published 2011
Packaging Tube
Operating Temperature -40°C~80°C
Physical
Package / Case 24-DIP Module, 9 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
