JCL3012D15
RoHS
/
Package 7-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCL3012D15 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 9 V, 18 V, 30 W, 15 V
PDF
/
Buying Options
Total Price: USD $82.36
Unit Price: USD $82.35988
≥1 USD $82.35988
≥10 USD $77.698
≥100 USD $73.3
≥500 USD $69.15094
≥1000 USD $65.23674
≥3000 USD $61.54409
Inventory: 4757
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 40.64mm
Height 10.2mm
Technical
Min Input Voltage (DC) 9V
Max Input Voltage (DC) 18V
Current - Output 2 1A
Nominal Output Voltage -15V
Max Output Power 30W
Current - Output 1 1A
Output Power 30W
Output Current 1A
Current - Output (Max) 1A 1A
Trim/Adjustable Output YES
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Operating Supply Voltage 12V
Max Output Current 1A
Output Voltage 15V
Voltage - Isolation 1.5kV
Efficiency 90%
Number of Outputs 2
JESD-30 Code R-XDMA-P7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 50.8mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Power Rating 30W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OCP, OTP, OVP, SCP
Size / Dimension 2.00Lx1.60W x 0.40 H 50.8mmx40.6mmx10.2mm
Series JCL30 (30W)
Published 2009
Operating Temperature -40°C~100°C With Derating
Physical
Weight 48g
Package / Case 7-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
