JCK3012D15
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCK3012D15 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 9 V, 18 V, 30 W, 15 V
PDF
/
Buying Options
Total Price: USD $57.75
Unit Price: USD $57.75304
≥1 USD $57.75304
≥10 USD $54.484
≥100 USD $51.4
≥1000 USD $45.74582
≥3000 USD $43.15643
Inventory: 954
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2010
Series JCK (30W)
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power Rating 30W
Max Power Dissipation 30W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 50.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-T6
Number of Outputs 2
Efficiency 91%
Voltage - Isolation 1.6kV
Output Voltage 15V
Max Output Current 1A
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 1A 1A
Output Current 1A
Output Power 30W
Control Features Enable, Active High
Voltage - Output 2 -15V
Current - Output 1 1A
Max Output Power 30W
Nominal Output Voltage -15V
Current - Output 2 1A
Max Input Voltage (DC) 18V
Min Input Voltage (DC) 9V
Dimensions
Height 10.16mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
