JCJ1012D12

XP Power
RoHS
RoHS RoHS compliant
Package 11-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER JCJ1012D12 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 9 V, 18 V, 10 W, 12 V
PDF
/
Buying Options
Total Price: USD $32.86
Unit Price: USD $32.86
≥1 USD $32.86
≥10 USD $31
≥100 USD $29.24528
≥1000 USD $26.0282
Inventory: 3674
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 11-DIP Module, 8 Leads
Weight 20g

Technical

Operating Temperature -40°C~100°C
Packaging Tube
Published 2009
Series JCJ (10W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type Isolated Module
Applications ITE (Commercial)
Power Rating 10W
Max Power Dissipation 10W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 31.75mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-MDMA-P8
Number of Outputs 2
Efficiency 87%
Voltage - Isolation 1.5kV
Output Voltage 12V
Max Output Current 416mA
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 416mA 416mA
Output Current 416mA
Output Power 10W
Voltage - Output 2 -12V
Current - Output 1 416mA
Max Output Power 10W
Current - Output 2 416mA
Max Input Voltage (DC) 18V
Min Input Voltage (DC) 9V

Dimensions

Height 10.16mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
