JCG1224D15
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 9 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER, DC/DC, 12W, +/-15V
PDF
/
Buying Options
Total Price: USD $36.04
Unit Price: USD $36.04
≥1 USD $36.04
≥10 USD $34
≥100 USD $32.07547
≥500 USD $30.25988
Inventory: 8180
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 10.16mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 36V
Current - Output 2 400mA
Nominal Output Voltage -15V
Max Output Power 12W
Current - Output 1 400mA
Voltage - Output 2 -15V
Control Features Enable, Active High
Output Power 12W
Output Current 400mA
Current - Output (Max) 400mA 400mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Operating Supply Voltage 24V
Max Output Current 400mA
Output Voltage 15V
Voltage - Isolation 1.6kV
Efficiency 91%
Number of Outputs 2
JESD-30 Code R-XDMA-P9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 31.75mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 12W
Power Rating 12W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series JCG (12W)
Published 2009
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Weight 20g
Package / Case 24-DIP Module, 9 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
