JCE0348S3V3

XP Power
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER JCE0348S3V3 Isolated Board Mount DC/DC Converter, 1.5kV Isolation, Fixed, 1 Output, 36 V, 75 V, 3 W, 3.3 V
PDF
/
Buying Options
Total Price: USD $20.22
Unit Price: USD $20.2248
≥1 USD $20.2248
≥10 USD $19.08
≥100 USD $18
Inventory: 4422
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 7 Leads

Technical

Operating Temperature -40°C~100°C
Packaging Tube
Published 2014
Series JCE (3W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
Type Isolated Module
Applications ITE (Commercial)
Max Power Dissipation 3W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 31.75mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-T7
Number of Outputs 1
Efficiency 75%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 3.3V
Max Output Current 900mA
Voltage - Output 1 3.3V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Output Power 3W
Current - Output 1 900mA
Max Output Power 3W
Max Input Voltage (DC) 75V
Min Input Voltage (DC) 36V

Dimensions

Height 10.16mm
Width 20.32mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
