JCE0348D24
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCE0348D24 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 36 V, 75 V, 3 W, 24 V
PDF
/
Buying Options
Total Price: USD $15.62
Unit Price: USD $15.61804
≥1 USD $15.61804
≥10 USD $14.734
≥100 USD $13.9
≥500 USD $13.11321
≥1000 USD $12.37095
≥3000 USD $11.67071
Inventory: 8861
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Length 31.75mm
Height 10.16mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 75V
Current - Output 2 63mA
Max Output Power 3W
Current - Output 1 63mA
Voltage - Output 2 -24V
Output Power 3W
Current - Output (Max) 63mA 63mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Output 1 24V
Max Output Current 63mA
Output Voltage 24V
Voltage - Isolation 1.5kV
Efficiency 79%
Number of Outputs 2
JESD-30 Code R-PDMA-T8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 20.32mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 3W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series JCE (3W)
Published 2014
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
