JCD0624S15
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCD0624S15 Isolated Board Mount DC/DC Converter, 2:1 Input, Fixed, 1 Output, 18 V, 36 V, 6 W, 15 V
PDF
/
Buying Options
Total Price: USD $23.85
Unit Price: USD $23.85
≥1 USD $23.85
≥10 USD $22.5
≥100 USD $21.22642
≥1000 USD $18.89143
Inventory: 2108
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 7 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2013
Series JCD (6W)
Size / Dimension 1.25Lx0.80W x 0.41 H 31.8mmx20.3mmx10.4mm
Feature OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type Isolated Module
Applications ITE (Commercial)
Power Rating 6W
Max Power Dissipation 6W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 31.75mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 24/8
JESD-30 Code R-XDMA-P8
Number of Outputs 1
Efficiency 83%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 36V
Output Voltage 15V
Max Output Current 400mA
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 400mA
Output Power 6W
Current - Output 1 400mA
Max Output Power 6W
Nominal Output Voltage 15V
Max Input Voltage (DC) 36V
Min Input Voltage (DC) 18V
Dimensions
Height 10.4mm
Width 20.32mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
