JCD0548S3V3
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCD0548S3V3 Isolated Board Mount DC/DC Converter, 2:1 Input, Fixed, 1 Output, 36 V, 72 V, 5 W, 3.3 V
PDF
/
Buying Options
Total Price: USD $21.24
Unit Price: USD $21.23604
≥1 USD $21.23604
≥10 USD $20.034
≥100 USD $18.9
≥500 USD $17.83019
≥1000 USD $16.82093
≥3000 USD $15.8688
Inventory: 1926
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 7 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2007
Series JCD (5W)
Size / Dimension 1.25Lx0.80W x 0.41 H 31.8mmx20.3mmx10.4mm
Feature OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type Isolated Module
Applications ITE (Commercial)
Power Rating 5W
Max Power Dissipation 4W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 31.75mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 24/8
JESD-30 Code R-XDMA-P8
Number of Outputs 1
Efficiency 76%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 72V
Output Voltage 3.3V
Max Output Current 1.3A
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Output Current 1.3A
Output Power 4.29W
Current - Output 1 1.3A
Max Output Power 5W
Nominal Output Voltage 3.3V
Max Input Voltage (DC) 72V
Min Input Voltage (DC) 36V
Dimensions
Height 10.4mm
Width 20.32mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
