JCD0448S15
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCD0448S15 Isolated Board Mount DC/DC Converter, 2:1 Input, Fixed, 1 Output, 36 V, 72 V, 4 W, 15 V
PDF
/
Buying Options
Total Price: USD $20.22
Unit Price: USD $20.2248
≥1 USD $20.2248
≥10 USD $19.08
≥100 USD $18
≥500 USD $16.98113
≥1000 USD $16.01994
≥3000 USD $15.11315
Inventory: 5169
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 20.32mm
Height 10.4mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 72V
Nominal Output Voltage 15V
Max Output Power 4W
Current - Output 1 266mA
Output Power 4W
Output Current 266mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Max Output Current 266mA
Output Voltage 15V
Voltage - Input (Max) 72V
Voltage - Isolation 1.6kV
Efficiency 81%
Number of Outputs 1
JESD-30 Code R-XDMA-P8
Pin Count 24/8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 31.75mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 4W
Power Rating 4W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP
Size / Dimension 1.25Lx0.80W x 0.41 H 31.8mmx20.3mmx10.4mm
Series JCD (4W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 24-DIP Module, 7 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
Alternative Model
