JCD0412D15

XP Power
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER JCD0412D15 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 9 V, 18 V, 4 W, 15 V
PDF
/
Buying Options
Total Price: USD $21.24
Unit Price: USD $21.23604
≥1 USD $21.23604
≥10 USD $20.034
≥100 USD $18.9
≥500 USD $17.83019
≥1000 USD $16.82093
≥3000 USD $15.8688
Inventory: 9845
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height 10.4mm

Technical

Min Input Voltage (DC) 9V
Max Input Voltage (DC) 18V
Current - Output 2 133mA
Nominal Output Voltage -15V
Max Output Power 4W
Current - Output 1 133mA
Voltage - Output 2 -15V
Output Power 4W
Output Current 133mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Max Output Current 133mA
Output Voltage 15V
Voltage - Isolation 1.6kV
Efficiency 80%
Number of Outputs 2
JESD-30 Code R-XDMA-P8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 31.75mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 4W
Power Rating 4W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP
Size / Dimension 1.25Lx0.80W x 0.41 H 31.8mmx20.3mmx10.4mm
Series JCD (4W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C

Physical

Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 10 Weeks
