JCB0348S24
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 14 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCB0348S24 Isolated Board Mount DC/DC Converter, 2:1 Input, Fixed, 1 Output, 36 V, 72 V, 3 W, 24 V
PDF
/
Buying Options
Total Price: USD $13.48
Unit Price: USD $13.4832
≥1 USD $13.4832
≥10 USD $12.72
≥100 USD $12
≥1000 USD $10.67996
≥3000 USD $10.07543
Inventory: 2078
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 20.32mm
Height 10.16mm
Technical
Min Input Voltage (DC) 36V
Max Input Voltage (DC) 72V
Nominal Output Voltage 24V
Max Output Power 3W
Current - Output 1 125mA
Output Power 3W
Output Current 125mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Max Output Current 125mA
Output Voltage 24V
Voltage - Input (Max) 72V
Voltage - Isolation 1.5kV
Efficiency 80%
Number of Outputs 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 31.75mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 3W
Power Rating 3W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP, UVLO
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series JCB (3W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 24-DIP Module, 14 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
