JCB0348D15
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 14 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCB0348D15 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 36 V, 72 V, 3 W, 15 V
PDF
/
Buying Options
Total Price: USD $13.47
Unit Price: USD $13.47196
≥1 USD $13.47196
≥10 USD $12.7094
≥100 USD $11.99
≥500 USD $11.31132
≥1000 USD $10.67106
Inventory: 4220
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 14 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2013
Series JCB (3W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Type Isolated Module
Applications ITE (Commercial)
Power Rating 3W
Max Power Dissipation 3W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 31.75mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-P14
Number of Outputs 2
Efficiency 80%
Voltage - Isolation 1.5kV
Output Voltage 15V
Max Output Current 100mA
Operating Supply Voltage 48V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 100mA 100mA
Output Current 100mA
Output Power 3W
Voltage - Output 2 -15V
Current - Output 1 100mA
Max Output Power 3W
Nominal Output Voltage -15V
Current - Output 2 100mA
Max Input Voltage (DC) 72V
Min Input Voltage (DC) 36V
Dimensions
Height 10.16mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
