JCA1024D01
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCA1024D01Isolated Board Mount DC/DC Converter, 2:1 Input, Through Hole, 10W, 5V, 800mA, -5V, 800mA
PDF
/
Buying Options
Total Price: USD $60.6
Unit Price: USD $60.59889
≥1 USD $60.59889
≥10 USD $57.16877
≥100 USD $53.9328
≥500 USD $50.88
≥1000 USD $48
≥3000 USD $45.28302
Inventory: 910
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 8 Leads
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.906mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 36V
Current - Output 2 800mA
Max Output Power 10W
Current - Output 1 800mA
Voltage - Output 2 -5V
Output Power 10W
Output Current 800mA
Current - Output (Max) 800mA 800mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Max Output Current 800mA
Output Voltage 5V
Voltage - Isolation 1.5kV
Efficiency 85%
Number of Outputs 2
JESD-30 Code R-XDMA-P8
Depth 25.4mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 8W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OCP, OVP, SCP, UVLO
Size / Dimension 1.00Lx0.80W x 0.39 H 25.4mmx20.3mmx10.0mm
Series JCA (10W)
Published 2013
Packaging Tube
Operating Temperature -40°C~100°C
