JCA0624D01
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER - JCA0624D01 - CONVERTER, DC/DC, 2O/P, 6W, +/-5V
PDF
/
Buying Options
Total Price: USD $36.7
Unit Price: USD $36.696
≥1 USD $36.696
≥10 USD $35.596
≥100 USD $34.496
≥500 USD $33.0264
≥1000 USD $30.826488
Inventory: 101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 8 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2007
Series JCA (6W)
Size / Dimension 1.00Lx0.80W x 0.39 H 25.4mmx20.3mmx10.0mm
Feature OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Applications ITE (Commercial)
Power (Watts) 6W
Power Rating 6W
Max Power Dissipation 5W
Depth 25.4mm
Number of Outputs 2
Efficiency 81%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 5V
Max Output Current 500mA
Voltage - Output 1 5V
Voltage - Input (Min) 18V
Current - Output (Max) 500mA 500mA
Output Current 500mA
Output Power 6W
Voltage - Output 2 -5V
Min Input Voltage 18V
Max Input Voltage 36V
Current - Output 1 500mA
Max Output Power 6W
Current - Output 2 500mA
Max Input Voltage (DC) 36V
Min Input Voltage (DC) 18V
Dimensions
Height 9.906mm
Length 25.4mm
Width 20.32mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
