JCA0605D02
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCA0605D02 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 4.5 V, 9 V, 6 W, 12 V
PDF
/
Buying Options
Total Price: USD $37.22
Unit Price: USD $37.22487
≥1 USD $37.22487
≥10 USD $35.1178
≥100 USD $33.13
≥500 USD $31.25472
≥1000 USD $29.48558
Inventory: 5967
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 8 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2007
Series JCA (6W)
Size / Dimension 1.00Lx0.80W x 0.39 H 25.4mmx20.3mmx10.0mm
Feature OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial)
Power Rating 6W
Max Power Dissipation 6W
Depth 25.4mm
Number of Outputs 2
Efficiency 83%
Voltage - Isolation 1.5kV
Output Voltage 12V
Max Output Current 250mA
Current - Output (Max) 250mA 250mA
Output Current 250mA
Output Power 6W
Voltage - Output 2 -12V
Current - Output 1 250mA
Max Output Power 6W
Current - Output 2 250mA
Max Input Voltage (DC) 9V
Min Input Voltage (DC) 4.5V
Dimensions
Height 9.906mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
