JCA0605D01
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCA0605D01 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 4.5 V, 9 V, 6 W, 5 V
PDF
/
Buying Options
Total Price: USD $37.28
Unit Price: USD $37.28105
≥1 USD $37.28105
≥10 USD $35.1708
≥100 USD $33.18
Inventory: 52
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.906mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 9V
Current - Output 2 500mA
Max Output Power 6W
Current - Output 1 500mA
Voltage - Output 2 -5V
Output Power 6W
Output Current 500mA
Current - Output (Max) 500mA 500mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Max Output Current 500mA
Output Voltage 5V
Voltage - Isolation 1.5kV
Efficiency 81%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-MDMA-P8
Depth 25.4mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 5W
Power Rating 6W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP, UVLO
Size / Dimension 1.00Lx0.80W x 0.39 H 25.4mmx20.3mmx10.0mm
Series JCA (6W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 16 Weeks
