JCA0448S05

XP Power
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER JCA0448S05 Isolated Board Mount DC/DC Converter, 2:1 Input, Fixed, 1 Output, 36 V, 75 V, 4 W, 5 V
PDF
/
Buying Options
Total Price: USD $38.24
Unit Price: USD $38.2448
≥1 USD $38.2448
≥10 USD $36.08
≥100 USD $34.03774
Inventory: 7262
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 20.3mm
Height 9.906mm

Technical

Min Input Voltage (DC) 36V
Max Input Voltage (DC) 75V
Nominal Output Voltage 5V
Max Output Power 4W
Current - Output 1 800mA
Output Power 4W
Output Current 800mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Max Output Current 800mA
Output Voltage 5V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MDMA-P7
Depth 25.4mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 4W
Power Rating 4W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP, UVLO
Size / Dimension 1.00Lx0.80W x 0.39 H 25.4mmx20.3mmx10.0mm
Series JCA (4W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C

Physical

Package / Case 24-DIP Module, 7 Leads
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 16 Weeks
