JCA0424D02
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCA0424D02 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 18 V, 36 V, 4 W, 12 V
PDF
/
Buying Options
Total Price: USD $40.94
Unit Price: USD $40.94398
≥1 USD $40.94398
≥10 USD $38.6264
≥100 USD $36.44
Inventory: 88
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.906mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 36V
Current - Output 2 170mA
Max Output Power 4W
Current - Output 1 170mA
Voltage - Output 2 -12V
Output Power 4W
Output Current 170mA
Current - Output (Max) 170mA 170mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Max Output Current 170mA
Output Voltage 12V
Voltage - Isolation 1.5kV
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-MDMA-P8
Depth 25.4mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 4W
Power Rating 4W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP, UVLO
Size / Dimension 1.00Lx0.80W x 0.39 H 25.4mmx20.3mmx10.0mm
Series JCA (4W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 16 Weeks
