JCA0205D02
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCA0205D02 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 4.5 V, 9 V, 2 W, 12 V
PDF
/
Buying Options
Total Price: USD $22.22
Unit Price: USD $22.2176
≥1 USD $22.2176
≥10 USD $20.96
≥100 USD $19.77358
≥500 USD $18.65433
≥1000 USD $17.59842
Inventory: 5257
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 9.906mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 9V
Current - Output 2 85mA
Nominal Output Voltage -12V
Max Output Power 2W
Nominal Input Voltage 5V
Current - Output 1 85mA
Output Power 2W
Output Current 85mA
Current - Output (Max) 85mA 85mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Max Output Current 85mA
Output Voltage 12V
Voltage - Isolation 1.5kV
Efficiency 73%
Number of Outputs 2
JESD-30 Code R-MDMA-P8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 25.4mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 2W
Power Rating 2W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP, UVLO
Size / Dimension 1.00Lx0.80W x 0.39 H 25.4mmx20.3mmx10.0mm
Series JCA (2W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 16 Weeks
