JAH0212S09
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 12 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JAH0212S09 Isolated Board Mount DC/DC Converter, 1kV Isolation, Fixed, 1 Output, 10.8 V, 13.2 V, 2 W, 9 V
PDF
/
Buying Options
Total Price: USD $19.1
Unit Price: USD $19.1012
≥1 USD $19.1012
≥10 USD $18.02
≥100 USD $17
≥500 USD $16.03774
≥1000 USD $15.12994
Inventory: 1655
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 24-DIP Module, 12 Leads
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Published 2007
Series JAH (2W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature SCP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
Type Isolated Module
Applications ITE (Commercial)
Power Rating 2W
Max Power Dissipation 2W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 31.75mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 1
Efficiency 68%
Voltage - Isolation 1kV
Voltage - Input (Max) 13.2V
Output Voltage 9V
Max Output Current 222mA
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Output Current 222mA
Output Power 2W
Current - Output 1 222mA
Nominal Input Voltage 12V
Max Output Power 2W
Nominal Output Voltage 9V
Max Input Voltage (DC) 13.2V
Min Input Voltage (DC) 10.8V
Dimensions
Height 10.16mm
Width 20.32mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Alternative Model
