JAH0205D09
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 12 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JAH0205D09 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 4.5 V, 5.5 V, 2 W, 9 V
PDF
/
Buying Options
Total Price: USD $20.2
Unit Price: USD $20.19963
≥1 USD $20.19963
≥10 USD $19.05626
≥100 USD $17.9776
≥500 USD $16.96
≥1000 USD $16
≥3000 USD $15.09434
Inventory: 3394
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 10.16mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 5.5V
Current - Output 2 111mA
Nominal Output Voltage -9V
Max Output Power 2W
Nominal Input Voltage 5V
Current - Output 1 111mA
Output Power 2W
Output Current 111mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Max Output Current 111mA
Output Voltage 9V
Voltage - Isolation 1kV
Efficiency 70%
Number of Outputs 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 31.75mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 2W
Power Rating 2W
Additional Feature ADDITIONAL -9V OUTPUT AVAILABLE
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP, UVLO
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Series JAH (2W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 24-DIP Module, 12 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
